Potius™ Panels are built predominately from engineered timber, resulting in a structurally efficient system with high dimensional accuracies.
The Potius™ Panel system is simple and efficient to install and can be customised for site specific requirements.
Potius™ Roof Panels can span up to 14m. Potius™ Floor Panels can span up to 9.5m.
Reduced Building Cost
Lightweight Potius™ Panels reduce loads on gravity and seismic system - reducing cranage requirements and overall building cost.
What R rating can your panels come in?
We can alter our foam thickness to achieve the desired amount of insulation requested. Typically we would insulate subfloors with R2.5, walls R3 and roofs R6.6 insulation.
Do I need my own architect and engineer for a Potius™ project?
Potius™ prefers to do all the engineering for its systems in-house by using its Chartered Engineers. Clients will need to engage their own architect for design of their project (Potius™ can recommend architects familiar with our system on request).
What is a typical panel size and weight?
Commercial panels are typically 2.4m wide x 8.0m long and weigh 600kgs each.
The maximum panels dimensions we can make are 3.0m wide x 12.0m long.
How long does it take to install a Potius™ commercial floor or roof system?
Commercial floors and roofs are generally installed in sections and up to 500m2 per day. Onsite storage is generally required as the panels can generally be produced quicker than they can be installed.
What is the lead time for ordering my Potius™ Panels?
Lead times may vary because of material supply and work load, however a typical lead time from ordering panels to delivery would be 1.5 - 2.5 months.
Can you provide indicative quotes for your panels so I can compare systems?
Yes, if we have a sketch or concept we can provide an estimate of cost for our panels.
Is the PUR Insulation environmental friendly?
The PUR insulation we use is Heatlok HFO Highlift, which uses recycled plastics, renewable soy oils and a non ozone depleting blowing agent. Because of its superior insulating properties its environment impact becomes less than glass fibre insulation early in its in service life cycle. Environmental Product Declarations are available on request.
Are Potius™ Panels able to be used on concrete foundations?
Yes, Potius™ Panels can be used on concrete or timber foundations.
Can Potius™ Panels be used in conjunction with traditional frame and truss construction?
Yes, Potius™ Panels can be mixed with traditional and other building systems as required.
